Features
Network Connections 12, 24, or 48 twisted-pair ports. The 12-port hub has built-in RJ-45 jacks.
The 24-port
and 48-port hubs have industry-standard 50-pin telco connectors
that can be fitted with 50-pin/RJ-45 Adapters included with the hubs.
A ThinLAN port (BNC) for connection to a ThinLAN coaxial cable segment.
This port is used to connect hubs together and to connect the hubs to a
common network backbone.
Upgradeable Design
The AUI/Xcvr slot for installing one of the HP Transceiver Modules.:
- HP Fiber-Optic Transceiver Module (HP J2606A)—for 10Base-FL
- HP Twisted-Pair Transceiver Module (HP J2607A)—for 10Base-T
- HP ThinLAN Transceiver Module (HP J2608A)—for 10Base2
- HP AUI Port Module (HP J2609A)—to attach external transceivers
Ability to expand the hubs’ capabilities by adding to the Expansion Slot the
following optional components:
- HP Ethernet SNMP Module
- HP AdvanceStack Dial-A-LAN 2A/Plus V.34
- HP AdvanceStack Dial-A-LAN 4A
- HP AdvanceStack Router 210 Module
Distributed Management
RJ-45 extension ports for “chaining” the HP AdvanceStack hubs together,
allowing access to all the hubs in the chain from one RS-232 out-of-band
connection into the chain, or from a network management station. The
out-of-band control is from a PC running HP Stack Manager or an ASCII
terminal or PC emulating an ASCII terminal.
The RS-232 out-of-band management port for attaching a personal computer
running the included Windows-based HP Stack Manager software or for
controlling the hub from an ASCII terminal or a PC emulating an ASCII terminal.
If the hub has an HP Ethernet SNMP Module installed, this serial connection
can also be made through a modem attached to the RS-232 port. The HP Stack
Manager software can also configure, monitor, and diagnose the hub or an
entire stack of hubs.
(continued on next page)
