HP AdvanceStack 10Base-T Hub-12 - Page 7

ThinLAN
network
port
chain ports RS-232 console port
(for distributed management)
Optional AUI port module
installed in AUI/Xcvr slot
twisted-pair ports
hub status LEDs
and reset button
twisted-pair port LEDs
cable management
guide
Front Panel
power connector
cover plate over slot for
HP Ethernet SNMP Module
Back Panel
redundant power
connector for the Hub-24
and Hub-48
vi
