HP BladeSystem c-Class Troubleshoot Manual

Component identification 77
Accessing the Insight Display on the HP BladeSystem c7000 Enclosure
The Insight Display is located on the front of the HP BladeSystem c7000 Enclosure. The Insight Display slides
from side to side to allow access to enclosure components.
HP BladeSystem Insight Display components
Item Description Function
1
Insight Display screen Displays Main Menu error messages and instructions
2
Left arrow button Moves the menu or navigation bar selection left one position
3
Right arrow button Moves the menu or navigation bar selection right one position
4
OK button Accepts the highlighted selection and navigates to the selected
menu
5
Down arrow button Moves the menu selection down one position
6
Up arrow button Moves the menu selection up one position
