Removal and replacement procedures 54
2.
Power down the enclosure (on page 29).
NOTE: Be sure to note the location of each removed component so it can be returned to its
original location after the midplane assembly is replaced.
3. Disconnect all cables from the enclosure.
4. Disengage and extend the following components approximately 8 cm (3 in):
o Half-height and full-height blades ("Half-height or full-height blade" on page 34)
o Power supplies ("HP BladeSystem c7000 power supply or power supply blank" on page 30)
— The power supply in bay 3 or 4 must be completely removed, and then the Insight Display must
be moved in front of that power supply bay to enable the other power supplies to be removed
or extended.
5. Remove the enclosure fans ("Active Cool 200 fan" on page 39).
6. Remove the interconnect switches and Pass-Thru modules ("Interconnect switch or Pass-Thru module" on
page 40).
7. Remove the Onboard Administrator modules ("Onboard Administrator" on page 43).
8. Remove the Onboard Administrator tray ("Onboard Administrator tray" on page 43).
CAUTION: When removing the rear cage and midplane assembly, the connectors on the
midplane assembly are susceptible to damage. Use caution to avoid damage to the pins and
connectors.
9. Remove the rear cage ("Rear cage" on page 45).
WARNING: To reduce the risk of personal injury or equipment damage, at least two people are
needed to safely move the rear cage.
10. Remove the Insight Display signal pass-thru board ("Insight Display signal pass-thru board" on page
49).
IMPORTANT: For platinum model enclosures, it s not necessary to remove the midplane
assembly from the rear cage. The midplane spare part includes the rear cage.
