Specifications 74
Specifications
Environmental specifications
Specification Value
Temperature range*
Operating
10°C to 35°C (50°F to 95°F)
Non-operating
-30°C to 60°C (-22°F to 140°F)
Wet bulb temperature
Operating
28ºC (82.4ºF)
Non-operating
38.7ºC (101.7ºF)
Relative humidity
(noncondensing)**
Operating
20% to 80%
Non-operating
5% to 95%
* All temperature ratings shown are for sea level. An altitude derating of 1°C per 304.8 m (1.8°F per 1000 ft) to 3048
m (10,000 ft) is applicable. No direct sunlight allowed. Upper operating limit is 3,048 m (10,000 ft) or 70 Kpa/10.1
psia. Upper non-operating limit is 9,144 m (30,000 ft) or 30.3 KPa/4.4 psia.
** Storage maximum humidity of 95% is based on a maximum temperature of 45°C (113°F). Altitude maximum for
storage corresponds to a pressure minimum of 70 KPa.
Enclosure specifications
Specification Value
Product dimensions
Height
442.0 mm (17.4 in)
Depth
813.0 mm (32.0 in)
Width
447.0 mm (17.6 in)
Shipping dimensions
Height
759.00 mm (29.88 in)
Depth
1013.00 mm (39.88 in)
Width
607.00 mm (23.88 in)
Single-phase enclosure weight*
Unboxed
54.9 kg (121.0 lb)
Shipping
74.4 kg (164.0 lb)
Three-phase enclosure weight*
