WLAN module
Description
HP WLAN 802.11 a/g/n, 2x2
HP WLAN 802.11 a/b/g/n, 2x2
The WLAN module is located on the left side of the system board. The module is secured with one Phillips
screw and has two connected antennas.
NOTE: The procedure to replace the WLAN module must be performed by an HP technician.
NOTE: WLAN module appearance may vary.
To remove the WLAN module:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 27).
2. Remove the access panel (see
Access panel on page 33).
3. Disconnect the antenna cables from the module (1).
4. Remove the Phillips screw (2) that secures the module to the computer.
ENWW WLAN module 49
