Lower rear panel
The lower rear panel is located under the stand and on the bottom rear of the computer. It is secured with
one screw.
To remove the lower rear panel:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 27).
2. Remove the access panel (see
Access panel on page 33).
3. Remove the stand (see
Stand on page 29).
ENWW Lower rear panel 59
