Processor
Description
AMD A10-7800B (3.7-GHz)
AMD A8-7600B (3.1-GHz)
AMD A6-7400B (3.5-GHz)
AMD A4-7350B (3.4-GHz)
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 27).
2. Remove the access panel (see
Access panel on page 33).
3. Remove the processor heat sink (see
Heat sink on page 51).
4. Rotate the locking lever to its full open position (1), and then carefully lift the processor from the
socket (2).
CAUTION: Do NOT handle the pins in the processor socket. These pins are very fragile and handling
them could cause irreparable damage. Once pins are damaged it may be necessary to replace the
system board.
NOTE: After installing a new processor onto the system board, always update the system ROM to ensure
that the latest version of the BIOS is being used on the computer. The latest system BIOS can be found on the
Web at:
http://www.hp.com.
ENWW Processor 53
