Webcam module
On products that ship with a webcam module, the module is located at the top of the computer beneath the
top rear trim. It is housed in a metal bracket that is secured with two Phillips screws. the webcam module has
one connector.
The webcam module is optional.
To remove the webcam module:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 27).
2. Remove the access panel (see
Access panel on page 33).
3. Remove the top rear trim (see
Top rear trim on page 54).
4. Remove the two Torx screws that secure the webcam module bracket to the computer.
ENWW Webcam module 55
