Removing and replacing an M.2 SSDRemoving and replacing an M.2 SSD
ProcedureProcedure
1. Power down the server (Power down the server).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
Extend the server from the rack ( Extend the server from the rack ).
Remove the server from the rack ( Remove the server from the rack ).
4. Remove the access panel ( Remove the access panel).
5. Remove the primary riser cage (Removing and replacing the primary or secondary PCIe riser cages ).
6. Remove the M.2 SSD.
To replace the component, reverse the removal procedure.
