Removing and replacing the small form factor universal media bayRemoving and replacing the small form factor universal media bay
ProcedureProcedure
1. Power down the server (Power down the server).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
Extend the server from the rack ( Extend the server from the rack ).
Remove the server from the rack ( Remove the server from the rack .
4. Remove the access panel ( Remove the access panel).
5. Remove all hot-plug hard drives ( Removing and replacing drives).
6. Remove the fan cage (Removing and replacing the fan cage ) .
7. Disconnect all cables from the universal media bay.
8. Remove the universal media bay.
To replace the component, reverse the removal procedure.
