Rear miscellaneous blanks kit spare partsRear miscellaneous blanks kit spare parts

Customer self repair: mandatorymandatory

DescriptionDescription Spare part numberSpare part number

Rear miscellaneous blanks kit 875067-001

4 LFF backplane bracket (3) —

Rear 2 SFF serial blank —

Secondary PCI blank —

PCI riser cage blank for optional board —

PCI riser cage blank for optional board, with screw —

Optional PCI serial blank —

Rear miscellaneous blanks kit spare parts 21
