HP Enterprise ProLiant DL380 Gen10

To Next Page

To Previous Page

1 Optical disk drive

2 Serial label pull tab

3 USB 3.0 port

4 iLO service port

5 Video display port

ItemItem DescriptionDescription

Front panel components 226
