8 x1 SATA port 4
9 Optical disk drive/SATA port 5
10 Power switch/SID module connector
11 Drive backplane power connectors
12 Energy pack connector
13 Chassis intrusion detection connector
14 Drive backplane power connector
15 microSD card slot
16 Dual internal USB 3.0 ports
17 Type-a Smart Array connector
18 Secondary PCIe riser connector*
19 System battery
20 Tertiary PCIe riser connector*
21 TPM connector
22 Serial port connector (optional)
ItemItem DescriptionDescription
* Requires a second processor
