260
Field Description
P0- P1- P2- P3- P4- P5- P6-
P7-
Number of supported priorities configured by using the
priority-flow-control no-drop dot1p
dot1p-list command on the
neighbor.
CoS map Application protocol-to-CoS mapping.
CBS
Indicates whether the token bucket mechanism is supported on
the port:
• False—The token bucket mechanism is not supported.
• True—The token bucket mechanism is supported.
Max TCs Maximum number of priorities supported.
TSA Transmission selection algorithm.
Value of MBC
MBC indicates the ability of packets to bypass MACsec. It is 1-bit
long.
• 0—Packets can bypass MACsec when MACsec is disabled.
• 1—Packets cannot bypass MACsec when MACsec is
disabled.
Port and protocol VLAN ID(PPVID) Port protocol VLAN ID.
Port and protocol VLAN supported Indicates whether protocol VLAN is supported on the port.
Port and protocol VLAN enabled Indicates whether protocol VLAN is enabled on the port.
VLAN name of VLAN 12 Name of VLAN 12.
Auto-negotiation supported Indicates whether autonegotiation is supported on the port.
Auto-negotiation enabled Indicates whether autonegotiation is enabled on the port.
OperMau Speed and duplex state on the port.
Power port class
PoE port class:
• PSE—Power sourcing equipment.
• PD—Powered device.
PSE power supported Indicates whether the device can operate as a PSE.
PSE power enabled Indicates whether the device is operating as a PSE.
PSE pairs control ability Indicates whether the pair selection ability is available.
Power pairs
Power supply mode:
• Signal—Uses data pairs to supply power.
• Spare—Uses spare pairs to supply power.
Port power classification
Power class of the PD:
• Class 0.
• Class 1.
• Class 2.
• Class 3.
• Class 4.
Power type
This field appears only on the devices that support PoE.
PD type of an LLDP neighboring device that is a PD device:
• Type 1 PD—Receives a power of 0 W to 15.4 W, a voltage of
44 V to 57 V, and a current of up to 350 mA.
• Type 2 PD—Receives a power of 0 W to 30 W, a voltage of 50
V to 57 V, and a current of up to 600 mA.
Power source This field appears only on the devices that support PoE.
