9
Figure 3 Mounting brackets for the HP 5930-2Slot+2QSFP+/HP 5930-2Slot+2QSFP+ TAA switch
Figure 4 Mounting brackets for the HP 5930-4Slot/HP 5930-4Slot TAA switch
(1) Cable mana
g
ement bracket (2) Mountin
g
bracket
Figure 5 1U rack mounting rail kit
(1) Chassis rail (2) Slide rail
1 2
1 2
