51
Table 11 Power supply specifications
Power supply Specifications Remarks
650W AC
• Rated input voltage:
100 VAC to 240 VAC @ 50 Hz or 60 Hz
• Max input voltage:
90 VAC to 264 VAC @ 47 Hz to 63 Hz
• Max output power:
650 W
For more information about the
power supplies, see HP A58x0AF
650W AC (JC680A) & 650W DC
(JC681A) Power Supplies User
Guide.
650W DC
• Rated input voltage:
–40 VDC to –60 VDC
• Max input voltage:
–40 VDC to –72 VDC
• Max output power:
650 W
Fan trays
Table 12 Fan tray specifications
Item Specifications
LSWM1HFANSC (for the HP 5930-32 QSFP+/HP 5930-32 QSFP+ TAA and HP
5930-2Slot+2QSFP+/HP 5930-2Slot+2QSFP+ TAA switches)
Fans Two 40 × 40 × 56 mm (1.57 × 1.57 × 2.2 in) fans
Fan speed 21000 R.P.M
Max airflow 70 CFM
Airflow direction Back to front (Fans draw air from the power supply side to the network port side.)
Input voltage 12 V
Maximum power
consumption
60 W
Documentation
reference
HP LSWM1HFANSC and LSWM1HFANSCB Fan Assemblies Installation
LSWM1HFANSCB (for the HP 5930-32 QSFP+/HP 5930-32 QSFP+ TAA and HP
5930-2Slot+2QSFP+/HP 5930-2Slot+2QSFP+ TAA switches)
Fans Two 40 × 40 × 56 mm (1.57 × 1.57 × 2.2 in) fans
Fan speed 21000 R.P.M
Max airflow 70 CFM
Airflow direction Front to back (Fans draw air from the network port side to the power supply side.)
Input voltage 12 V
Maximum power
consumption
60 W
Documentation
reference
HP LSWM1HFANSC and LSWM1HFANSCB Fan Assemblies Installation
