Appendix C Ports and LEDs
Ports
Console port
The switch has two console ports: serial console port and Mini USB console port.
Table 14 Console port specifications
Item Console port Mini USB console port
Connector type RJ-45 USB mini-Type B
Compliant
standard
EIA/TIA-232 USB 2.0
Transmission baud
rate
9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII terminal.
• Provides connection to the serial port of a
local or remote (through a pair of modems)
PC running terminal emulation program.
• Provides connection to an ASCII
terminal.
• Provides connection to the USB port
of a local PC running terminal
emulation program.
Management Ethernet port
The switch has one management Ethernet port. You can connect this port to a PC or management station
for loading and debugging software or remote management.
Table 15 Management Ethernet port specifications
Item Specification
Connector type RJ-45
Connector quantity 1
Port transmission rate 10/100/1000 Mbps, half/full duplex
Transmission medium and max
transmission distance
100 m (328.08 ft) over category-5 twisted pair cable
Functions and services Switch software and Boot ROM upgrade, network management
