HP JG726A - QSFP+ Port

57
Product
code
HP description Max transmission distance Data rate
JD097B HP X240 10G SFP+ SFP+ 3m DA Cable 3 m (9.84 ft) 10.31 Gbps
JG081C HP X240 10G SFP+ SFP+ 5m DA Cable 5 m (16.40 ft) 10.31 Gbps
Figure 59 SFP+ DAC cable
(1) Connector (2) Pull latch
NOTE:
HP recommends that you use HP SFP transceiver modules, SFP+ transceiver modules, or SFP+ DAC cables
for the SFP+ ports on the switch. The HP SFP transceiver modules, SFP+ transceiver modules, and SFP+
DAC cables are subject to change over time. For the most up-to-date list of SFP transceiver modules, SFP+
transceiver modules, and SFP+ DAC cables, contact HP Support or marketing staff.
For more information about HP SFP transceiver modules, SFP+ transceiver modules, and SFP+ DAC
cables, see HP Transceiver Modules User Guide.
QSFP+ port
The HP 5930-32 QSFP+/HP 5930-32 QSFP+ TAA and HP 5930-2Slot+2QSFP+/HP
5930-2Slot+2QSFP+ TAA switches provide fixed QSFP+ ports. The LSWM18QC, LSWM124XGT2Q,
LSWM124XG2Q, LSWM124XG2QL, and LSWM124XG2QFC interface modules provide QSFP+ ports.
You can install 40G QSFP+ transceiver modules in 0, 4
0G QSFP+ DAC cables in Table 20, and 40G
QSFP+ to SFP+ DAC cables in Table 21 i
n the QSFP+ ports as needed.
Table 19 40G QSFP+ transceiver modules available for the QSFP+ ports
Product
code
HP description
Central
wavelength
(nm)
Connector
Fiber type
and
diameter
(μm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
JG325B
HP X140 40G
QSFP+ MPO
SR4 Transceiver
850 MPO
Multi-mode,
50/125
2000
100 m
(328.08 ft)
4700
150 m
(492.12 ft)
JG709A
HP X140 40G
QSFP+ MPO
850 MPO
Multi-mode,
50/125
2000
300 m
(984.25 ft)
