HP ProCurve Series 2810 User Manual

6-25
Quality of Service (QoS): Managing Bandwidth More Effectively
Using QoS Types To Configure QoS for Outbound Traffic
For example, suppose you wanted to assign these DSCP policies to the packets
identified by the indicated UDP and TDP port applications:
1. Determine whether the DSCPs already have priority assignments, which
could indicate use by existing applications. (Also, a DSCP must have a
priority configured before you can assign any QoS types to use it.)
Figure 6-6. Display the Current DSCP-Map Configuration
Port Applications DSCP Policies
DSCP Priority
23-UDP 000111 7
80-TCP 000101 5
914-TCP 000010 1
1001-UDP 000010 1
The DSCPs for this
example have not yet
been assigned an
802.1p priority level.

HP ProCurve Series 2810 Specifications

General

Layer	Layer 2
Form Factor	Rack-mountable
Power Supply	Internal
Jumbo Frame Support	Yes
Uplink Ports	4 x dual-personality ports (10/100/1000 or mini-GBIC)
Switching Capacity	48 Gbps
Throughput	35.7 Mpps
Forwarding Rate	35.7 million pps
Management	Web, SNMP, CLI
MAC Address Table Size	16000 entries
Routing Protocol	Static routing
Features	VLAN support, QoS, IGMP snooping
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	15% to 95% non-condensing
Model	HP ProCurve Series 2810
Ports	24 x 10/100/1000 (Gigabit)
