Illustrated Parts Catalog
1-4 HP ProLiant DL320 Generation 3 Server Maintenance and Service Guide
Mechanical Parts and System Components Spares List
Table 1-1: Mechanical and System Spare Parts List
Item Description Spare Part Number Customer
Self Repair
Mechanical Components
1 Access panel 378631-001 Yes
2 PCI-X riser board assembly 361387-001 Yes
3 Fan assembly 378701-001 Yes
Power
4 500-Watt power supply 378630-001 Yes
Boards
5 LED/PWR switch board 378627-001 Yes
6 PCI Express board* 378626-001 Yes
7 System board 378623-001 Yes
8 SATA Backplane 378625-001 Yes
Processor
9 a) 2.93-GHz Intel® Celeron® processor 378619-001 Yes
b) 3.4-GHz Intel Pentium® 4 processor 1MB* 378620-001 Yes
c) 3.4-GHz Intel Pentium 4 processor 2 MB * 384787-001 Yes
d) 3.6-GHz Intel Pentium 4 processor 1 MB* 378621-001 Yes
10 Heatsink 378622-001 Yes
Memory
11 a) PC3200 DDR ECC Registered DIMM 512 MB 351657-001 Yes
b) PC3200 DDR ECC Registered DIMM 1 GB* 351658-001 Yes
Mass Storage Devices
12 Optical devices/diskette assembly
a) CD-ROM 390629-001 Yes
b) DVD-ROM * 383981-001 Yes
c) SCSI hard drive
1. SCSI 18-GB U320 HD
2. SCSI 36-GB U320 HD
3. SCSI 72-GB U320 HD
1. 289240-001
2. 289241-001
3. 289243-001
Yes
Yes
Yes
d) SATA hard drive
1. SATA 80-GB HD
2. SATA 160-GB HD
3. SATA 250-GB HD
1. 353042-001
2. 353043-001
3. 353044-001
Yes
Yes
Yes
e) Diskette drive assembly* 390530-001 Yes
* Not shown
