Removal and Replacement Procedures
2-28 HP ProLiant DL320 Generation 3 Server Maintenance and Service Guide
To install a DIMM:
1. Gently push the DIMM into the socket on the system board (1). When the DIMM is
properly seated, the latches close (2).
Figure 2-23: Installing a DIMM in a DIMM socket
CAUTION: Use only HP supplied DIMMs. DIMMs from other sources can adversely affect
data integrity.
2. Press down firmly on the DIMM while pushing the latches inward until the latches snap
into place.
