Removal and Replacement Procedures
HP ProLiant DL320 Generation 3 Server Maintenance and Service Guide 2-19
Fans
The server contains four system fans. The fans are located on the fan assembly. Use Figure 2-
15 and Table 2-1 to locate the system fans.
Figure 2-15: Locating the system fans
NOTE: Fans are spared and replaced individually. Each fan listed in Table 2-1 is a separate spare.
Table 2-1: System Fans
Item Component
1 Fan 1
2 Fan 2
3 Fan 3
4 Fan 4
