Removal and Replacement Procedures
2-10 HP ProLiant DL320 Generation 3 Server Maintenance and Service Guide
Figure 2-5: Remove the Optical drive
To replace the optical drive, reverse steps 1 through 4.
NOTE: See the HP ProLiant DL320 Generation 3 Server User Guide for instructions on installing the
optical drive.
NOTE: If the drive must be replaced due to failure, the optical drive backplane must be removed from
the failed drive and installed on the replacement. See Chapter 1, “Illustrated Parts Catalog,” for
illustrations.
