Removal and Replacement Procedures
2-12 HP ProLiant DL320 Generation 3 Server Maintenance and Service Guide
Figure 2-6: SATA device numbers
SATA Hard Drives
To remove a hard drive from the hard drive bay:
1. Power down the server. See “Powering Down the Server” in this chapter.
2. Flip open the tray lever to release the hard drive tray (1), and then slide the tray out of the
chassis (2).
Figure 2-7: Removing the SATA hard drive tray from the chassis
