19. Replace the cover. (See “Removing and Replacing the Top Cover on a Rack-Mounted Server”
(page 53).)
20. Reconnect the power and external cables and turn on the server.
21. Verify processor installation by using the system utilities.
• Use the iLO MP commands to verify operation
• Use the BCH commands to verify operation
• Use MAKODIAG provided by the offline diagnostic environment to exercise the processor
added
Replacing the System Battery
The server has two batteries. The main system battery is located on the system board. The other
battery is located on the underside of the iLO MP card.
Battery Notice
This product contains a Lithium battery.
WARNING! Lithium batteries can explode if mistreated. Do not recharge, disassemble, or
dispose of lithium batteries in a fire. Failure to observe this warning can result in personal injury
or damage to equipment.
Replace only with the identical or equivalent battery. Follow the manufacturer’s recommendations.
Dispose of used batteries according to the manufacturer's instructions.
Replacing the System Battery
To replace the system battery, follow these steps:
1. Power off the server and disconnect the power and external cables.
2. Remove the cover. (See “Removing and Replacing Server Covers and Bezels” (page 52) for
instructions.)
3. Remove the memory airflow guide (see “Removing and Replacing the Memory Airflow
Guide” (page 65)).
4. Remove the processor airflow guide, the front portion of the processor airflow guide, and
fans 1A and 1B (see “Removing and Replacing the Processor Airflow Guide” (page 66)).
5. Lift up the battery retaining clip with a flat-head screwdriver and push on the back of the
battery to remove the battery from its holder.
Installing Additional Components 85
