HP xw6400 User Manual

3. Lift the green drive-lock release lever 1 and gently slide the drive 2 out of the chassis.
Figure 4-34 Removing the optical drive from the chassis
To :
1. Lift the green drive-lock release lever while sliding the optical drive into the bay. When the optical
drive is partially inserted, release the drive-lock release lever and slide the drive inward until the
drive snaps into place, securing the drive.
CAUTION Ensure that the optical drive is secure. Failure to do so can cause damage to
the drive when moving the workstation.
2. Connect the power, data, and audio (if required) cables to the drive and workstation.
NOTE The audio cable is only required for Linux-based systems.
ENWW Removal and replacement of components 85

HP xw6400 Specifications

General

Chipset	Intel 5000X
Storage	SATA or SAS hard drives
Power Supply	650W
Memory	Up to 16 GB DDR2
Expansion Slots	2 PCIe x16
Network	Integrated Gigabit Ethernet
Operating System	Windows XP Professional
Graphics	NVIDIA Quadro FX series
