HPE FlexFabric 5700 Series Configuration Guide

109
Verifying the configuration
Suppose the optical fiber between Device A and Device B fails. You can use the display smart-link
group command to display the smart link group configuration on a device.
# Display the smart link group configuration on Device C.
[DeviceC] display smart-link group all
Smart link group 1 information:
Device ID : 000f-e23d-5af0
Preemption mode : ROLE
Preemption delay: 1(s)
Control VLAN : 10
Protected VLAN : Reference Instance 1
Member Role State Flush-count Last-flush-time
-----------------------------------------------------------------------------
XGE1/0/1 PRIMARY DOWN 5 16:45:20 2014/04/21
XGE1/0/2 SECONDARY ACTIVE 1 16:37:20 2014/04/21
Smart link group 2 information:
Device ID : 000f-e23d-5af0
Preemption mode : ROLE
Preemption delay: 1(s)
Control VLAN : 110
Protected VLAN : Reference Instance 2
Member Role State Flush-count Last-flush-time
-----------------------------------------------------------------------------
XGE1/0/2 PRIMARY ACTIVE 5 16:45:20 2014/04/21
XGE1/0/1 SECONDARY STANDBY 1 16:37:20 2014/04/21
The output shows that primary port Ten-GigabitEthernet 1/0/1 of smart link group 1 fails, and
secondary port Ten-GigabitEthernet 1/0/2 is in forwarding state.

HPE FlexFabric 5700 Series Specifications

General

Product Line	HPE FlexFabric
Model	5700 Series
Power Supply	Redundant power supply options
Layer Support	Layer 2/3
Management	HPE Intelligent Management Center (IMC), CLI, SNMP
Routing Protocol	RIP, OSPF, BGP, IS-IS
Features	Virtualization
Compliant Standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad, IEEE 802.3ae
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% (noncondensing)
Latency	Less than 1 µs
