HPE FlexFabric 5700 Series Configuration Guide

96
Task Command
Display information about the received flush
messages.
display smart-link flush
Display smart link group information.
display smart-link group
{ group-id |
all
}
Clear the statistics about flush messages.
reset smart-link statistics
Smart Link configuration examples
Single smart link group configuration example
Network requirements
As shown in Figure 24:
• Device C and Device D are Smart Link devices. Device A, Device B, and Device E are
associated devices. Traffic of VLANs 1 through 30 on Device C and Device D is dually uplinked
to Device A.
• Configure Smart Link on Device C and Device D for dual uplink backup.
Figure 24 Network diagram
Configuration procedure
1. Configure Device C:
# Create VLANs 1 through 30, map these VLANs to MSTI 1, and activate the MST region
configuration.
<DeviceC> system-view
[DeviceC] vlan 1 to 30
[DeviceC] stp region-configuration
[DeviceC-mst-region] instance 1 vlan 1 to 30
[DeviceC-mst-region] active region-configuration
[DeviceC-mst-region] quit

HPE FlexFabric 5700 Series Specifications

General

Product Line	HPE FlexFabric
Model	5700 Series
Power Supply	Redundant power supply options
Layer Support	Layer 2/3
Management	HPE Intelligent Management Center (IMC), CLI, SNMP
Routing Protocol	RIP, OSPF, BGP, IS-IS
Features	Virtualization
Compliant Standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad, IEEE 802.3ae
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% (noncondensing)
Latency	Less than 1 µs
