58
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Create an RRPP ring group
and enter RRPP ring group
view.
rrpp ring-group
ring-group-id
By default, no RRPP ring group is
created.
3. Assign the specified subrings
to the RRPP ring group.
domain
domain-id
ring
ring-id-list
By default, no subrings are
assigned to an RRPP ring group.
Displaying and maintaining RRPP
Execute display commands in any view and reset commands in user view.
Task Command
Display brief RRPP information.
display rrpp brief
Display RRPP group configuration information.
display rrpp ring-group
[ ring-group-id ]
Display RRPPDU statistics.
display rrpp statistics
domain
domain-id [
ring
ring-id ]
Display detailed RRPP information.
display rrpp verbose domain
domain-id [
ring
ring-id ]
Clear RRPPDU statistics.
reset rrpp statistics domain
domain-id [
ring
ring-id ]
RRPP configuration examples
Single ring configuration example
Network requirements
As shown in Figure 19:
• Device A, Device B, Device C, and Device D form RRPP domain 1. Specify the primary control
VLAN of RRPP domain 1 as VLAN 4092. Specify the protected VLANs of RRPP domain 1 as
VLANs 1 through 30.
• Device A, Device B, Device C, and Device D form primary ring 1.
• Specify Device A as the master node of primary ring 1, Ten-GigabitEthernet 1/0/1 as the primary
port, and Ten-GigabitEthernet 1/0/2 as the secondary port.
• Specify Device B, Device C, and Device D as the transit nodes of primary ring 1. Specify
Ten-GigabitEthernet 1/0/1 as the primary port and Ten-GigabitEthernet 1/0/2 as the secondary
port on Device B, Device C, and Device D.
