163
Forwarder 02
State : Active
Virtual MAC : 000f-e2ff-4012 (Owner)
Owner ID : 0000-5e01-1103
Priority : 255
Active : local
Forwarder 03
State : Listening
Virtual MAC : 000f-e2ff-4013 (Learnt)
Owner ID : 0000-5e01-1105
Priority : 127
Active : FE80::3
Forwarder Weight Track Information:
Track Object : 1 State : Positive Weight Reduced : 250
The output shows that when Switch A fails, Switch B becomes the master because it has a
higher priority than Switch C, and the VF for virtual MAC address 000f-e2ff-4011 is removed.
Troubleshooting VRRP
An error prompt is displayed
Symptom
An error prompt "The virtual router detected a VRRP configuration error." is displayed during
configuration.
Analysis
This symptom is probably caused by the following reasons:
• The VRRP advertisement interval in the packet is not the same as that for the current VRRP
group (in VRRPv2 only).
• The number of virtual IP addresses in the packet is not the same as that for the current VRRP
group.
• The virtual IP address list is not the same as that for the current VRRP group.
• A device in the VRRP group receives illegitimate VRRP packets. For example, the IP address
owner receives a VRRP packet with the priority 255.
Solution
• Modify the configuration on routers in VRRP groups to ensure consistent configuration.
• Take fault location and anti-attack measures to eliminate potential threats.
Multiple masters appear in a VRRP group
Symptom
Multiple masters appear in a VRRP group.
Analysis
It is normal for a VRRP group to have multiple masters for a short time, and this situation requires no
manual intervention.
