HPE FlexFabric 5710 Series User Manual

11
Figure 11 Attaching the mounting brackets and chassis rails to an HPE 5710-54HF switch
(mounting brackets installed near the power supply side)
Figure 12 Attaching the mounting brackets and chassis rails to an HPE 5710-54HT switch
(mounting brackets installed near the power supply side)
Figure 13 Attaching the mounting brackets and chassis rails to an HPE 5710-30HT switch
(mounting brackets installed near the power supply side)
Connecting the grounding cable to the chassis
CAUTION:
Select grounding points as required. The primary grounding point and auxiliary grounding point are
located on the left side panel. If you use one of these grounding points, you must connect the
grounding cable to the grounding point before you mount the switch in the rack.
This section uses the primary grounding point on the HPE 5710-54HF switch as an example.
To connect the grounding cable to a grounding point:
1. Choose a grounding point. As a best practice, use the grounding point close to the mounting
brackets.
2. Unpack the grounding cable and grounding screws.
You can use the cable and screws shipped with the switch for connecting to the primary
grounding point or auxiliary grounding point.

HPE FlexFabric 5710 Series Specifications

General

Model	HPE FlexFabric 5710 Series
Power Supply	AC or DC
Operating Temperature	0°C to 45°C
Routing Protocol	OSPF, BGP, RIP
Input Voltage	100-240V AC
Operating Humidity	10% to 90% (non-condensing)
Jumbo Frame Support	Up to 9216 bytes
Management	CLI, SNMP
