253
[SwitchB-keychain-abc-key-1] accept-lifetime utc 10:00:00 2015/02/06 to 11:00:00
2015/02/06
[SwitchB-keychain-abc-key-1] quit
# Create key 2 for keychain abc, specify an authentication algorithm, and configure a key string and
the sending and receiving lifetimes for the key.
[SwitchB-keychain-abc] key 2
[SwitchB-keychain-abc-key-2] authentication-algorithm hmac-md5
[SwitchB-keychain-abc-key-2] key-string plain pwd123
[SwitchB-keychain-abc-key-2] send-lifetime utc 11:00:00 2015/02/06 to 12:00:00 2015/02/06
[SwitchB-keychain-abc-key-2] accept-lifetime utc 11:00:00 2015/02/06 to 12:00:00
2015/02/06
[SwitchB-keychain-abc-key-2] quit
[SwitchB-keychain-abc] quit
# Configure VLAN-interface 100 to use keychain abc for authentication.
[SwitchB] interface vlan-interface 100
[SwitchB-Vlan-interface100] ospf authentication-mode keychain abc
[SwitchB-Vlan-interface100] quit
Verifying the configuration
1. When the system time is within the lifetime from 10:00:00 to 11:00:00 on the day 2015/02/06,
verify the status of the keys in keychain abc.
# Display keychain information on Switch A. The output shows that key 1 is the valid key.
[SwitchA] display keychain
Keychain name : abc
Mode : absolute
Accept tolerance : 0
TCP kind value : 254
TCP algorithm value
HMAC-MD5 : 5
MD5 : 3
Default send key ID : None
Active send key ID : 1
Active accept key IDs: 1
Key ID : 1
Key string : $c$3$dYTC8QeOKJkwFwP2k/rWL+1p6uMTw3MqNg==
Algorithm : md5
Send lifetime : 10:00:00 2015/02/06 to 11:00:00 2015/02/06
Send status : Active
Accept lifetime : 10:00:00 2015/02/06 to 11:00:00 2015/02/06
Accept status : Active
Key ID : 2
Key string : $c$3$7TSPbUxoP1ytOqkdcJ3K3x0BnXEWl4mOEw==
Algorithm : hmac-md5
Send lifetime : 11:00:00 2015/02/06 to 12:00:00 2015/02/06
