hpmont HD3N Series User Manual

Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
- 94 - HD3N Series User Manual V1.1
Ref. code Function Description Setting Range [Default]
F19.33
Action of length when length is met
0 - 2 [0]
F19.34 Action of length at stop 0 - 2 [0]
0: Clear to 0.
1: Remain.
2: Continue calculating.
A
ux PID limit (F19.35 - F19.36)
Ref. code Function Description Setting Range [Default]
F19.35
Aux PID output limit
0.0 - 100.0 [100.0%]
When aux frequency selects PID, adjustment upper limit of PID output = F19.35
×
main setting frequency.
F19.36 Aux PID output setting 0.0 - 100.0 [0.0%]
Aux PID output setting = output llimit of F19.35 + F19.36
×
F00.06.
F
requency adjustment range (F19.37)
Ref. code Function Description Setting Range [Default]
F19.37 Frequency adjustment range 000 - 111 [100]
Unit: main frequency calculating range
• 0: 0-max. frequency.
• 1: Negative max. frequency- max. frequency.
Ten: Aux frequency calculating range
• 0: 0-max. frequency.
•
1: Negative max. frequency- max. frequency.
Hundred: Resultant frequency calculating range
• 0: 0-upper limit frequency.
• 1: Negative upper limit frequency–upper limit
frequency.
S
hort-circuit detection (F19.38)
Ref. code Function Description Setting Range [Default]
F19.38
Inter-phase short-circuit detection
0,1 [1]
Used to detect inter-phase short-circuit before running HD3N.
0: Do not detect.
1: Detect.
I
nput voltage selection (F19.39)
Ref. code Function Description Setting Range [Default]
F19.39
Inout voltage selection
0 - 2 [0]
0: 380 - 460V.
1: 260 - 460V.
2: 200 - 460V.
Note: when F19.39 = 1 or 2, HD3N needs derating to use, and the actual output current should not surpass rated
output current of HD3N.
B
raking function (F19.24 - F19.25, F19.40 - F19.41)
Ref. code Function Description Setting Range [Default]
F19.40
Flux braking PI regulator Kp
0 - 4000 [1000]
F19.41
Flux braking PI regulator Ki
0 - 500 [20]
