8.3 Reactor Selection
The reactor selections is shown as Table 8-2
。
Table 8-2 Reactor selection
Model
AC input reactor AC output reactor DC reactor
Model
Parameter
(mH-A)
Model
Parameter
(mH-A)
Model
Parameter
(mH-A)
HD3N-4T037G HD-AIL-4T037 0.19/75 HD-AOL-4T037 0.08/80
- -
HD3N-4T045G HD-AIL-4T045 0.16/90 HD-AOL-4T045 0.06/100
HD3N-4T055G HD-AIL-4T055 0.13/115 HD-AOL-4T055 0.04/125
HD3N-4T075G HD-AIL-4T075 0.093/150 HD-AOL-4T075 0.035/160
HD3N-4T090G HD-AIL-4T090 0.08/180 HD-AOL-4T090 0.03/200 HD-DCL-4T090 0.14/240
HD3N-4T110G HD-AIL-4T110 0.067/210 HD-AOL-4T110 0.02/225 HD-DCL-4T110 0.12/290
HD3N-4T132G HD-AIL-4T132 0.055/255 HD-AOL-4T132 0.016/280 HD-DCL-4T132 0.11/330
HD3N-4T160G HD-AIL-4T160 0.046/305 HD-AOL-4T160 0.013/320 HD-DCL-4T160 0.09/400
HD3N-4T200G
HD3N-4T200G-C
HD-AIL-4T200 0.037/380 HD-AOL-4T200 0.011/400 HD-DCL-4T200 0.07/500
HD3N-4T220G
HD3N-4T220G-C
HD-AIL-4T220 0.034/415 HD-AOL-4T220 0.01/450 HD-DCL-4T220 0.06/550
HD3N-4T250G
HD3N-4T250G-C
HD-AIL-4T250
0.026/530
HD-AOL-4T250
0.009/560
HD-DCL-4T250
0.05/700
HD3N-4T280G
HD3N-4T280G-C
HD-AIL-4T280 HD-AOL-4T280 HD-DCL-4T280
HD3N-4T315G
HD3N-4T315G-C
HD-AIL-4T315 0.023/600 HD-AOL-4T315 0.007/630 In-built -
HD3N-4T355G
HD3N-4T355G-C
HD-AIL-4T355
0.019/760
HD-AOL-4T355
0.006/800
In-built -
HD3N-4T400G
HD3N-4T400G-C
HD-AIL-4T400 HD-AOL-4T400 In-built -
