Shenzhen Hpmont Technology Co., Ltd. Chapter 8 Accessories
HD3N Series User Manual V1.1 - 109 -
8.2 Braking Unit and Braking Resistor
The braking unit and braking resistor selection is shown as Table 8-1. For wiring, see section 4.3.2
Supply and Motor Connection, on page 21.
Table 8-1 Braking unit and braking resistor selection
Model
Motor
(kW)
Braking unit
Recommend value (Ω)
Lifting type None lifting type
Min. resistor Min. power Resistor Min. power
HD3N-4T7P5G 7.5 kW In-built 45 Ω 2.4 kW 60 - 80 Ω 800 W
HD3N-4T011G 11 kW In-built 40 Ω 3.6 kW 40 - 50 Ω 1.2 kW
HD3N-4T015G 15 kW In-built 25 Ω 4.5 kW 30 - 40 Ω 1.5 kW
HD3N-4T018G 18.5 kW In-built 20 Ω 6 kW 25 - 30 Ω 2 kW
HD3N-4T022G 22 kW In-built 18 Ω 7.5 kW 20 - 25 Ω 2.5 kW
HD3N-4T030G 30 kW In-built 15 Ω 9 kW 15 - 20 Ω 3 kW
HD3N-4T037G 37 kW Optional 12 Ω 12 kW 15 - 20 Ω 4 kW
HD3N-4T045G 45 kW Optional 10 Ω 13.5 kW 10 - 15 Ω 4.5 kW
HD3N-4T055G 55 kW Optional 9 Ω 16.5 Kw 10 - 15 Ω 5.5 kW
HD3N-4T075G 75 kW Optional 6 Ω 22.5 kW 8 - 10 Ω 7.5 kW
HD3N-4T090G 90 kW HDBU-4T150 6 Ω 27 kW 8 - 10 Ω 9 kW
HD3N-4T110G 110 kW HDBU-4T150 6 Ω 33 kW 6 - 8 Ω 11 kW
HD3N-4T132G 132 kW HDBU-4T250 4 Ω 40 kW 6 - 8 Ω 13.2 kW
HD3N-4T160G 160 kW HDBU-4T250 4 Ω 48 kW 4 - 6 Ω 16 kW
HD3N-4T200G
HD3N-4T200G-C
200 kW HDBU-4T250 4 Ω 60 kW 4 - 6 Ω 20 kW
HD3N-4T220G
HD3N-4T220G-C
220 kW HDBU-4T250*2 4 Ω*2 33 kW *2 6 - 8 Ω*2 11 kW *2
HD3N-4T250G
HD3N-4T250G-C
250 kW HDBU-4T250*2 4 Ω*2 37.5 kW *2 6 - 8 Ω*2 12.5 kW *2
HD3N-4T280G
HD3N-4T280G-C
280 kW HDBU-4T250*2 4 Ω*2 42 kW *2 4 - 6 Ω*2 14 kW *2
HD3N-4T315G
HD3N-4T315G-C
315 kW HDBU-4T250*2 4 Ω*2 48 kW *2 4 - 6 Ω*2 16 kW *2
HD3N-4T355G
HD3N-4T355G-C
355 kW HDBU-4T250*3 4 Ω*3 33 kW *3 4 - 6 Ω*3 11 kW *3
HD3N-4T400G
HD3N-4T400G-C
400 kW HDBU-4T250*3 4 Ω*3 42 kW *3 4 - 6 Ω*3 14 kW *3
Remarks: *2, *3 means 2, 3 parallel ways.
Note:
1. Please select braking resistor based on the above table.
Bigger resistor can protect the braking system in fault condition, but oversized resistor may bring a
capacity decrease, lead to over voltage protection.
2. The braking resistor should be mounted in a ventilated metal housing to prevent inadevertent contact
during it works, for the temperature is high.
