Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Function Introduction
HD3N Series User Manual V1.1 - 53 -
6.2.2 F01: Protection of Parameters
Ref. code Function Description Setting Range [Default]
F01.00
User password
00000 - 65535 [00000]
XXXXX: To enable the password protection function, set any non-zero number as the password.
• Once the password is set, to change any parameter, input correct password. Otherwise, all the
parameters cannot be changed but only read.
• When input correct password, by pressing button ( ) to exit to stop / run display status or by
detecting no press on the keypad within 5 minutes, the user’s password will be valid. To change
parameters, input correct password. It will restart when there is no press on the keypad within 5
minutes.
00000: The factory setting of F01.00 is 00000, namely the password protection function is disabled.
• If user unlocks the password, it means clearing the user’s password.
•
Refer to section 5.3 for more information about unlock/modify and clear password.
F01.01
Menu mode
000 - 101 [000]
Units:
• 0: Full menu mode. All function parameters can
be displayed.
• 1: Checking menu mode. Only parameters
different from factory setting can be displayed.
Ten: Unused
Hundreds:
• 0: Group F can check after setting password.
• 1: Group F can not check after setting password.
F01.02
Function code parameter initialization (download)
0 - 6 [0]
0: No operation. HD3N is in regular parameter read / write status.
• Whether can change the parameter depends on user password status
and the actual running condition of HD3N.
1: Restore to factory settings.
• Except F01.00, F01.02, F01.03, Group F08, F19.15, F19.19, F19.24, F20.08,
F20.09, F20.21 - F20.37, F23.00 and Group y.
• Steps: If set F01.02 = 1, press to ensure and the parameters are
restored to factory settings. The keypad dispalys “rESEt”. Then the
keypad will display parameters in stop status after finish restoring to
factory setting.
2,3: Download the keypad EEPROM parameter 1 / 2 to the current function code settings.
4: Clear fault information. The fault history of F20.21 - F20.37 will be cleared.
5,6: Copy the keypad EEPROM parameter 1 / 2 to the current function code settings (including the motor
parameters).
Note:
1. F01.00, F01.02, F01.03, F20.21 - F20.37 and group y can not be copied.
2. Parameter copying (no. 2/3/5/6 function ) is valid when LED keypad adopted.
F01.03 Copy parameter to keypad (upload) 0 - 2 [0]
0: No operation. HD3N is in regular parameter read / write status.
1: Copy the current function code settings to keypad EEPROM parameter 1.
2: Copy the current function code settings to keypad EEPROM parameter 2.
Note:
1. F01.00, F01.02, F01.03, F20.21 - F20.37 and group y can not be copied.
2. Parameter copying (no. 1/2 function) is valid when LED keypad adopted.
F01.02 = 2 / 3 / 5 / 6
HD3N
Keypad
Download
Keypadstored
function parameter
F01.03 = 1 / 2
Inverter
Keypad
Upload
Present setting
function parameter
6
