hpmont HD3N Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD3N Series User Manual V1.1 - 111 -
Appendix A Parameters
Attributes are changed:
”*”: It denotes that the value of this parameter is the actual value which cannot be modified.
“
×
”: It denotes that the setting of this parameter cannot be modified when the controller is in run
status.
”
○
”: It denotes that the setting parameter can be modified when the controller is in run status.
“
―
”: It denotes that the parameters have same mapping.
Ref. Code
Function Setting Range Default Unit Attribute Setting
d00: Status Display Parameter (on pages 46 - 49)
d00.00 HD3N series 0x10 - 0x50 *
d00.01 Software version of HD3N 00.00 - 99.99 *
d00.03
Non-standard software
version of HD3N
00.00 - 99.99 *
d00.05
Software version of
keypad
00.00 - 99.99
Valid only when LED adopted
*
d00.06 Customized serial number 0 - 9999 *
d00.07 Motor and control mode
Unit: Unused
Ten: Control mode
0: V/f control without PG
2: Vector control without PG
*
d00.08 Rated current of HD3N (A) 0.1A *
d00.10 Inverter status
Bit0: Inverter fault
Bit1: Run/Stop
Bit2: Forward/Reverse
Bit3: Zero speed
Bit5&Bit4: Acc. / Dec./Constant
Bit7: DC brake
Bit8: Auto-tuning
Bit10: Speed limitation
Bit11: Control mode
Bit12: Stall overvoltage
Bit13: Software current restriction
Bit14: Hardware current restriction
*
d00.11
Main setting frequency
channel
0 - 14 *
d00.12
Main setting frequency
(Hz)
0.01 - 400.00Hz *
d00.13 Aux setting frequency (Hz) 0.01 - 400.00Hz *
d00.14 Setting frequency (Hz) 0.01 - 400.00Hz *
d00.15
Setting frequency (after
Ac/Dec) (Hz)
0.01 - 400.00Hz *
d00.16 Output frequency (Hz) 0.01 - 400.00Hz *
A
