Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd.
- 8 - HD3N Series User Manual V1.1
Input / Output
Analogue power supply +10V, max. current 100mA
Digital power supply +24V, max. current 200mA
Analogue input
AI1: voltage 0 - 10V
AI2: 0V - +10V/0 - 20mA (selectable voltage/current)
Analogue output AO1, AO2: 0 - 10V/0 - 20mA (selectable voltage/current)
Analogue input DI1 - DI6; DI6 can be selectable for high speed pulse signal
Digital output DO1, DO2; DO2 can be selectable for high-frequency pulse signal output
Relay output R1A/R1B/R1C: Contact rating: 250VAC/3A or 30VDC/1A
SCI communication A, B
Keypad
LCD keypad 8 buttons, 5 units 8 segment LED display, 5 unit indicators, 5 status indicators
Optional LED keypad Optional: HD-LED-P/HD-LED-P-S
LCD / LED display Set parameter setting, check status parameter and fault code etc
Parameter copy LED can achieve parameter copying
Environment
Running temperature
-10 - +40
℃
, max. 50
℃
, air temperature fluctuation is less than 0.5
℃
/min
The derating value of the output current of HD3N shall be 2% for each degree
centigrade above 40
℃
. Max. allowed temperature is 50
℃
Storage temperature -40 - +70
℃
Location for use
Indoor, preventing from direct sunlight, no dust, corrosive, flammable gases,
oil mist, water vaper, dripping or salt etc.
Altitude Less than 1000 meters, otherwise should be derating use
Humidity Less than 95%RH, non-condensing
Vibration Resistance It is 3.5m/s
2
in 2 - 9Hz, it is 10m/s
2
(IEC60721-3-3) in 9 - 200Hz
Protection class IP20
Pollution level Level 2 (Dry, non conducting dust pollution)
Accessories
About keypad
LED keypad with potentiometer (HD-LED-P) and extension mounting base
(HD-KMB)
Small keypad (HD-LED-P-S) and extension mounting base (HD-KMB-S)
1m/2m/3m/6m extension cable to keypad (HD-CAB-1M/2M/3M/6M)
