Chapter 4 Electrical Installation Shenzhen Hpmont Technology Co., Ltd.
- 20 - HD3N Series User Manual V1.1
Frame 8 - Frame 11 / Frame 10 - Frame 11 (-C) supply and motor terminal
Frame 12 / Frame 12 (-C) supply and motor terminal
PE
L1 L2
L3
P1
(+) (-)
POWER
PE
U
V W
MOTOR
PE
L1 L2 L3
(+) (-)
POWER
PE
U V W
MOTOR
