NOTE
Fireproof clay can be used only for sealing the cable outlet hole in the base. It cannot be used for sealing
the cable outlet hole of the cabinet.
Step 3 Tighten the screws on the front baffle plate of the base.
----End
15.2 Applying Touch-Up Paint
The paint on the surface is intact. If any paint is damaged, you must apply touch-up paint to
avoid erosion.
Prerequisite
Before applying touch-up paint, select the same color as the original coating, as listed in Table
15-1.
Table 15-1 Code of color samples
Object Color Code of Huawei
Color Sample
International
Color Code
Cabinet (including the
APM30H, RFC, TMC11H,
IBBS200T, and IBBS200D)
RAL7035 YB026 RAL7035
Base 3010 Light
gray
YB030 Pontone 422U
Procedure
Step 1 If there are stains in the damaged area or rust on the material, use fine sandpaper to polish the
damaged area to remove the stains or rust.
Step 2 Use clean cotton cloth to remove the stains or dust from the surface of the area to be polished
or repaired.
Step 3 Shake the paint well, and then use a small brush inside the bottle to absorb paint and evenly
spread the paint on the damaged area until the area is covered.
CAUTION
The paint coating should be as thin as possible. No drops are allowed on the paint coating, and
the surface should be smooth.
Step 4 Perform subsequent operations after the repaired paint coating is exposed in the air for 30
minutes.
BTS3900A(Ver.B)
Installation Guide 15 Subsequent Operations
Issue 01 (2011-10-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
158
