9.1 Installing a Cabinet on the Base
This section describes the procedure and precautions for installing a cabinet of the BTS3900A
on a base.
Procedure
l Installing the BTS3900A on the base
1. Remove the four plastic screws from the top of the cabinet, and then install the lifting
lugs in the corresponding holes, as shown in Figure 9-1.
CAUTION
Reserve the plastic screws for later use.
Figure 9-1 Installing the lifting lugs
(1) Plastic screw
(2) Lifting lug
2. Install ropes on the lifting lugs, and then lift the cabinet, as shown in Figure 9-2.
BTS3900A(Ver.B)
Installation Guide 9 Installing the Cabinet
Issue 01 (2011-10-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
45
