Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
76
Item
Specification
Typical heat dissipation
DC: 2595.5 BTU/hour (fully configured with
LPUF-51s)
AC: 3082.2 BTU/hour (fully configured with
LPUF-51s)
DC: 2984.9 BTU/hour (fully configured with
LPUF-120s)
AC: 3471.5 BTU/hour (fully configured with
LPUF-120s)
DC input voltage
input voltage range: 38.4 V to 72 V
input rated voltage: 48 V/ 60 V
AC input voltage
input voltage range: 180 V to 264 V
input rated voltage: 200 V to 240 V
MTBF
27.44 years
MTTR
0.5 hours
Availability
0.99999792
Slot quantity
5
Redundant MPUs
1:1
Redundant Switch fabrics
N/A
Redundant fans
Support for proper fan operation in case of a single fan
failure for a short period at 40°C (104°F)
Redundant power supply
1+1
Forwarding performance
225 Mpps (LPUF-51)
360 Mpps (LPUF-120)
Switching capacity
1.08 Tbps
Operating temperature
Long-term: C to 45°C (32°F to 113°F)
Short-term: C to +55°C (23°F to131°F)
Remark: Restriction on the temperature variation
rate: 30°C/hour (86°F/h)
Storage temperature
40°C to +70°C (40°F to +158°F)
Relative operating humidity
Long term: 5% to 85% RH, non-condensing
Short term: 5% to 95% RH, non-condensing
