NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
84
Slot Name
Slot Quantity
Slot ID
Remarks
LPU
8
1 to 8
These slots hold
LPUs.
SRU
2
9 to 10
These slots hold
SRUs.
SFU
1
11
These slots hold
SFUs.
Interface Numbering
An interface is numbered in the format of Slot number/card number/Port number
Slot number: The slots of LPUs are numbered from 1 to 8. The slot number increases from left to right
facing the front panel of the NE40E (there are corresponding marks on the panel).
Card number: The cards of LPUs are numbered from top to bottom and from right to left beginning
with 0. If there is no card on a board, the card number is set to 0.
Port number: The ports of LPUs are numbered from left to right and from top to bottom beginning with
0.
Technical Specifications
Item
Specification
Dimensions (H x W x D)

(14 U) 620 mm x 442 mm x 650 mm (24.41 in. x
17.40 in. x 25.59 in.)(Chassis main body)

(14 U) 620 mm x 442 mm x 770 mm (24.41 in. x
17.40 in. x 30.31 in.)(Dimensions of the chassis
body together with cable trays and front and back
attachments)
Weight (empty)
25.8 kg (56.89 lb) (without filler panels)
Weight (full configuration)
136 kg (299.88 lb)
Cabinet installation standard
Can be installed in a standard 19" 800 mm-deep
cabinet. A Huawei 2.2 m-high N68E cabinet is used by
default.
Typical power consumption
3220 W (fully configured with LPUF-240s)
Typical heat dissipation
10447 BTU/hour (fully configured with LPUF-240s)
DC input voltage

input voltage range: –38.4 V to –72 V

input rated voltage: –48 V/ –60 V
