Huawei SUN2000-3KTL-M1 User Manual

Category Status Description
Blinking
green at
long
intervals
(on for 1s
and then
o for 1s)
O The DC is on and the AC
is o.
Blinking
green at
long
intervals
(on for 1s
and then
o for 1s)
Blinking green at long
intervals (on for 1s and
then o for 1s)
Both the DC and AC are
on, and the SUN2000 is
not supplying power to
the power grid.
O Blinking green at long
intervals (on for 1s and
then o for 1s)
The DC is o and the AC
is on.
O O Both the DC and AC are
o.
Blinking
red at
short
intervals
(on for
0.2s and
then
o
for 0.2s)
- DC environment alarm.
For example, the input
voltage of the PV string is
high, the PV string is
reversely connected, or
the insulation resistance
is low.
- Blinking red at short
intervals
AC environment alarm.
For example, the power
grid is undervoltage,
overvoltage,
overfrequency, or
underfrequency.
Steady red Steady red Fault
Communica
tions
indicator
LED3 -
Blinking green at short intervals (on
for 0.2s and then o for 0.2s)
Communication is in
progress. (When a mobile
phone is connected to
the SUN2000, the
indicator blinks green at
long intervals, indicating
that the phone is
connected to the
SUN2000.)
SUN2000-(3KTL-10KTL)-M1
User Manual 2 Overview
Issue 02 (2020-11-20) Copyright © Huawei Technologies Co., Ltd. 11

Huawei SUN2000-3KTL-M1 Specifications

General

Model	SUN2000-3KTL-M1
Type	String Inverter
Max. DC Input Voltage	600 V
MPPT Voltage Range	90 V - 560 V
Rated AC Output Power	3000 W
Max. AC Output Power	3300 W
Nominal AC Voltage	220 V / 230 V / 240 V
AC Voltage Range	180 V - 280 V
AC Output Frequency	50 Hz / 60 Hz
Max. Efficiency	98.6%
MPPT Trackers	2
DC Inputs per MPPT	1
Max. Input Current per MPPT	11 A
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Degree	IP65
Max. DC Input Power	4500 W
Communication	RS485
Dimensions (W x H x D)	365 mm x 365 mm x 156 mm
