Huawei SUN2000-3KTL-M1 User Manual

Table 5-1 Component description
No. Component Description Source
A PV module ● A PV string is composed of
the PV modules connected
in series and can work with
an optimizer.
● The SUN2000 supports the
input from two PV strings.
Prepared by users
B (Optional)
Smart PV
optimizer
The SUN2000-450W-P smart
PV optimizer is supported.
Purchased from
Huawei
C (Optional)
Battery
The LUNA2000-5-S0,
LUNA2000-10-S0, and
LUNA2000-15-S0 batteries can
be connected to the SUN2000.
Purchased from
Huawei
D (Optional)
Smart
Dongle
1
Supported models:
● WLAN-FE Smart Dongle:
SDongleA-05
● 4G Smart Dongle:
SDongleA-03
Purchased from
Huawei
E (Optional)
SUN2000
Select a proper model as
required.
Purchased from
Huawei
F (Optional)
SmartLogger
Select a proper model as
required.
Purchased from
Huawei
G (Optional)
Power meter
The DTSU666-H power meter is
recommended.
Purchased from
Huawei
H (Optional)
Power grid
scheduling
device
Select the devices that meet
the power grid scheduling
requirements.
Provided by the
local power grid
company
I (Optional)
Rapid
shutdown
switch
Select a proper model as
required.
Prepared by users
SUN2000-(3KTL-10KTL)-M1
User Manual 5 Electrical Connections
Issue 02 (2020-11-20) Copyright © Huawei Technologies Co., Ltd. 32

Huawei SUN2000-3KTL-M1 Specifications

General

Model	SUN2000-3KTL-M1
Type	String Inverter
Max. DC Input Voltage	600 V
MPPT Voltage Range	90 V - 560 V
Rated AC Output Power	3000 W
Max. AC Output Power	3300 W
Nominal AC Voltage	220 V / 230 V / 240 V
AC Voltage Range	180 V - 280 V
AC Output Frequency	50 Hz / 60 Hz
Max. Efficiency	98.6%
MPPT Trackers	2
DC Inputs per MPPT	1
Max. Input Current per MPPT	11 A
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Degree	IP65
Max. DC Input Power	4500 W
Communication	RS485
Dimensions (W x H x D)	365 mm x 365 mm x 156 mm
