Huawei SUN2000-3KTL-M1 User Manual

No. Component Description Source
J AC switch Recommended: a three-phase
AC circuit breaker with a rated
voltage greater than or equal
to 380 V AC and a rated
current of:
● 16 A (SUN2000-3KTL-M1,
SUN2000-4KTL-M1,
SUN2000-5KTL-M1, and
SUN2000-6KTL-M1)
● 25 A (SUN2000-8KTL-M1
and SUN2000-10KTL-M1)
Prepared by users
K (Optional)
Smart Backup
Box
Select a proper model as
required.
Purchased from
Huawei
Note 1:
● For details about how to operate the WLAN-FE Smart Dongle SDongleA-05,
see SDongleA-05 Quick Guide (WLAN-FE) .
● For details about how to operate the 4G Smart Dongle SDongleA-03, see
SDongleA-03 Quick Guide (4G) .
You can obtain the quick guide at https://support.huawei.com/enterprise/en/
index.html by searching for the Smart Dongle model.
Table 5-2 Cable description
No.
Name Type Recommended
Specications
1 DC input power cable Common outdoor PV
cable in the industry
(Recommended
model: PV1-F)
● Conductor cross-
sectional area: 4–6
mm
2
● Cable outer
diameter: 5.5–9
mm
2 (Optional) Battery
cable
3 (Optional) Signal
cable
a
Outdoor shielded
twisted pair
● Conductor cross-
sectional area: 0.2–
1 mm
2
● Cable outer
diameter: 4–11 mm
SUN2000-(3KTL-10KTL)-M1
User Manual 5 Electrical Connections
Issue 02 (2020-11-20) Copyright © Huawei Technologies Co., Ltd. 33

Huawei SUN2000-3KTL-M1 Specifications

General

Model	SUN2000-3KTL-M1
Type	String Inverter
Max. DC Input Voltage	600 V
MPPT Voltage Range	90 V - 560 V
Rated AC Output Power	3000 W
Max. AC Output Power	3300 W
Nominal AC Voltage	220 V / 230 V / 240 V
AC Voltage Range	180 V - 280 V
AC Output Frequency	50 Hz / 60 Hz
Max. Efficiency	98.6%
MPPT Trackers	2
DC Inputs per MPPT	1
Max. Input Current per MPPT	11 A
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Degree	IP65
Max. DC Input Power	4500 W
Communication	RS485
Dimensions (W x H x D)	365 mm x 365 mm x 156 mm
