Huawei SUN2000-3KTL-M1 User Manual

Indicators Status Remarks Description
Blinking red
and green
alternatively
Blinking at long
intervals (on for
1s and then o for
1s)
Abnormal No communication
with the SUN2000
– Remove and then
insert the Smart
Dongle.
– Check whether the
SUN2000 matches
the Smart Dongle.
– Connect the Smart
Dongle to another
SUN2000.
Check whether the
Smart Dongle is
faulty or the USB
port of the
SUN2000 is faulty.
Green Blinking at long
intervals (on for
0.5s on and then
o for 0.5s)
Normal Connecting to the
router.
Green Steady on Connected to the
management system.
Green Blinking at short
intervals (on for
0.2s and then o
for 0.2s)
The SUN2000
communicates with
the management
system through the
Smart Dongle.
● 4G Smart Dongle
Table 6-4 Indicator description
Indicators
Status Remarks Description
- O Normal The Smart Dongle is
not secured or not
powered on.
Yellow
(blinking
green and red
simultaneousl
y)
Steady on Normal The Smart Dongle is
secured and powered
on.
Green The blinking
interval is 2s. The
indicator is on for
Normal Dialing (lasting for
less than 1 minute)
SUN2000-(3KTL-10KTL)-M1
User Manual 6 Commissioning
Issue 02 (2020-11-20) Copyright © Huawei Technologies Co., Ltd. 64

Huawei SUN2000-3KTL-M1 Specifications

General

Model	SUN2000-3KTL-M1
Type	String Inverter
Max. DC Input Voltage	600 V
MPPT Voltage Range	90 V - 560 V
Rated AC Output Power	3000 W
Max. AC Output Power	3300 W
Nominal AC Voltage	220 V / 230 V / 240 V
AC Voltage Range	180 V - 280 V
AC Output Frequency	50 Hz / 60 Hz
Max. Efficiency	98.6%
MPPT Trackers	2
DC Inputs per MPPT	1
Max. Input Current per MPPT	11 A
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Degree	IP65
Max. DC Input Power	4500 W
Communication	RS485
Dimensions (W x H x D)	365 mm x 365 mm x 156 mm
