Figure 9-2 Turning on the maintenance bypass switch (60 kVA/80 kVA/120
kVA)
Step 3 After you turn on the maintenance bypass switch, the Maint. breaker closed
alarm is displayed on the LCD and WebUI.
----End
9.4 Transferring from Maintenance Bypass Mode to
Normal Mode
Prerequisites
Before transferring the UPS from maintenance bypass mode to normal mode,
ensure that the bypass input and output are normal.
Procedure
Step 1 Turn o the maintenance bypass switch.
1. Turn the maintenance bypass switch from the ON position to the OFF
position.
2. Lock the maintenance bypass switch if a lock is available.
