Huawei UPS5000-A-H Series User Manual

Item Specications
Battery voltage ● UPS5000-A-30KTTL/UPS5000-A-40KTTL/UPS5000-A-80KTTL/UPS5000-
A-60KTTL/UPS5000-A-120KTTL:
360–528 V DC (12 V batteries, 30 to 44 batteries, 32 batteries by default)
– 32–44 batteries: The output power is not derated.
– 30 batteries: The output power is derated to 94%.
NOTE
If the MDU and power versions are earlier than V100R002C01SPC007, the battery
voltage is 360–480 V DC (30–40 batteries, 32 batteries by default).
● UPS5000-A-60KTTL-H/UPS5000-A-120KTTL-H:
360–528 V DC (12 V batteries, 30–44 batteries, 40 batteries by default)
– 40–44 batteries: The output power is not derated.
– 36 and 38 batteries: The output power in battery mode is derated to 90%.
– 32 and 34 batteries: The output power in battery mode is derated to 80%.
– 30 batteries: The output power in battery mode is derated to 75%.
One-click cold
start
In the case of a mains failure, batteries can start the UPS to power loads.
Battery string
sharing
Battery string sharing is supported in a parallel system. No batteries are shared
within a UPS by default.
Charger output
power
Max. 5 kW
Charge voltage ● Equalized charge voltage: 2.3–2.4 V/cell, default: 2.35 V/cell (30–44
batteries)
● Float charge voltage: 2.23–2.3 V/cell, default: 2.25 V/cell (30–44 batteries)
3.8 Output Electrical Specications
Item
Specications
Output
system
Three-phase, four-wire, and PE
Rated
voltage
380/400/415 V AC±1% (line voltage)
Frequency In normal mode, the mains frequency is synchronous with the bypass input
frequency.
In battery mode, the frequency is 50 Hz/60 Hz with a tolerance of ±0.05%.
UPS5000-A-(30 kVA-120 kVA)
User Manual 3 Technical Specications
Issue 17 (2024-02-21) Copyright © Huawei Digital Power Technologies Co., Ltd. 57

Huawei UPS5000-A-H Series Specifications

General

Brand	Huawei
Model	UPS5000-A-H Series
Category	UPS
Language	English
